OEM/ODM Fiber Switch 4 8 16 24 48 port 10/100M Fiber switch
Features
◆ 10*10/100Base-TXRJ45 ports ,which is more convenient for users to flexibly set up to meet the network requirements of various scenarios.
◆ IEEE 802.3af/at PoE standard, without damaging non-PoE devices.
◆48*10/100Base-TX RJ45 ports, meeting the needs of security monitoring, teleconferencing system, wireless coverage, and other scenarios
◆ Switching system using store-and-forward.
◆ All ports support wire-speed switching, support for jumbo frame transmission.
◆ Panel indicator monitoring status and help failure analysis.
◆ Priority system for PoE port, it will supply power to the high priority level port first when the power budget is insufficient
◆ Support non-blocking wire-speed forwarding
◆ Support Poe Management POE Switch
Specifications
| Interface Characteristics | |
| Fixed Port | 48*10/100Base-TX PoE ports (Data/Power)
+ 1 * Gigabit RJ45 port + 2 * Gigabit Combo ports |
| Ethernet Port | 10/100Base-T(X) automatic detection, full/half Duplex MDI/MDI-X adaptive |
| Twisted Pair Transmission | 10BASE-T: Cat3,4,5 UTP(≤100 meter)
100BASE-TX: Cat5 or later UTP(≤100 meter) 1000BASE-T: Cat5e or later UTP(≤100 meter) |
| Chip Parameter | |
| Network Protocol | IEEE802.3 10BASE-T, IEEE802.3i 10Base-T, IEEE802.3u 100Base-TX IEEE802.3ab 1000Base-T, IEEE802.3z 1000Base-X, IEEE802.3x |
| Forwarding Mode | Store and Forward(Full Wire Speed) |
| Switching Capacity | 30Gbps |
| Forwarding Rate@64byte |
11.61Mpps |
| Mac | 16K |
| Buffer Memory | 4M |
| LED Indicator | Power: PWR (green); Network: Link（yellow）; POE :PoE (green) |
| PoE & Power | |
| PoE Port | Port 1 to 48 IEEE802.3af/at @ POE |
| Power Supply Pin | Default: 1/2 (+), 3/6 (-) ; Optional 4/5(+), 7/8(-) |
| Max Power Per Port | 30W; IEEE802.3af/at |
| Total PWR / Input Voltage | 600W (AC100-240V) |
|
Power Supply |
Built-in power adapter, AC 100~240V 50-60Hz 6.6A |
| Power Consumption | Standby<35W, Full load<600W |
| Physical Parameter | |
| Operation TEMP / Humidity | -20~+55°C;5%~90% RH Non condensing |
| Storage TEMP / Humidity | -40~+75°C;5%~95% RH Non condensing |
| Dimension (L*W*H) | 440*290*44.5mm |
| Net /Gross Weight | <3.0kg / <3.8kg |
| Installation | Desktop, Wall-mounted |
| Certification & Warranty | |
| Lightning protection | Lightning protection: 4KV 8/20us; Protection level: IP30 |
| Warranty | 2 years , lifelong maintenance. |
Applications
Widely used in:
● Widely used in:
● Smart city,
● Corparate Networking
● Security Monitoring
● Wireless Coverage
● Industrial Automation System
● IP phone (teleconferencing system), etc.
