Ethernet gigabit 5 POE ports + 1*SFP 802.3af/at Industrial Switch
Features
1. 4*2.5Gbps Ethernet port with auto-negotiation function
2. 2*10Gbps SFP slots
3.Support 2.5Gbps speed rate,MDI/MDIX
4.Support IEEE802.3x Flow control and back pressure control
5.Each port has the complete LED Indicator light
6.Support IEEE802.1d Spanning Tree
7.Each port supports wire-speed switching ,64~1518 frame length can reach the wire speed
8.Support high performance QoS function on each port
9.Support multicast to avoid network congestion
10.Support 5-16V voltage input
11.Support 4K lightning protection of each port
Specifications
|
Model |
HX-33064PFG |
HX-33064PFG-at |
| Interface | 4*10/100/1000Base-T POE ports(Data/Power)
1*10/100/1000M uplink RJ45 port (Data) 1*1000M SFP slot port (Data) |
|
| POE port | Port1-4 support POE @ IEEE802.3af/at | |
| Network Protocol | IEEE802.3 10BASE-T; IEEE802.3i 10Base-T;
IEEE802.3u 100Base-TX IEEE802.3ab 1000Base-T IEEE802.3z 1000Base-X IEEE802.3x |
|
| PoE Standard | IEEE802.3af/at international standard | |
| Ethernet Port Feature | 10/100/1000 BaseT,auto-sensing, full/half duplex MDI/MDI-X | |
| Forwarding Mode | Store and Forward(Full Wire Speed) | |
| Switching Capacity | 20Gbps | |
| Forwarding
Rate@64byte |
8.93Mpps | |
| MAC
Address Table |
8K | |
| Buffer Memory | 2M | |
| Twisted Pair Transmission | 10BASE-T:Cat3,4,5 UTP(≤100 meter)
100BASE-TX :Cat5 or later UTP(≤100 meter) 1000BASE-T:Cat6e or later UTP(≤100 meter) |
|
| Optical cable | multi-mode:850nm 0~550M.
Single-mode :1310nm 0~40KM,1550nm 0~120KM. |
|
| Power Supply Pin | Default: 1/2(+),3/6(-); | |
| Max /Average Power Per Port | 30W/15.4W
|
30W/30W |
| Total PWR / Input Voltage | 60W(48~57VDC) | 120W(48~57VDC) |
| Power Consumption | Standby<4W;
Full load<60W |
Standby<5W;
Full load<120W |
| LED | Power indicator: PWR (Green);network indicator: Link/Act (yellow); POE indicator: PoE (green); SFP port indicator :G6 (green) | |
| Power Supply | No, see the accessory information sheet for purchase. | |
| Storage TEMP / Humidity | -40~+85°C;5%~95% RH; Non condensing |
| Dimension(L*W*H) | 119*100*30mm |
| Net /Gross Weight | <0.88kg /<1.2kg |
| Installation Method | desktop type.DIN Rail type |
| Warranty |
5 years, lifelong maintenance. |
Applications
Widely used in:
● Widely used in:
● Smart city,
● Corparate Networking
● Security Monitoring
● Wireless Coverage
● Industrial Automation System
● IP phone (teleconferencing system), etc.
