8 Ports PoE Switch + 2 Ethernet uplink port Unmanaged Network switches

Short Description:

This model of switch is our self-developed standard 100M 8+2POE switch with 8 100M power supply ports and 2 100M RJ45 uplink ports. Adopting the latest high-speed Ethernet switching chip and ultra-high backplane bandwidth design, it has extremely fast data processing capabilities, improving smooth data transmission.

It has flexible scalability, easy to install and use, no configuration required, plug and play, strong compatibility, high-speed transmission, no packet loss, network not limited by power line layout, and cost saving.

Send email to us

Product Detail

Detail

Applications

OUR FACTORY

Product Tags

Features

◆ 8* 10/100M PoE Ports+2*10/100Mbps RJ45 Uplink port;

◆ Compatible with IEEE802.3at (30W) and IEEE802.3af (15.4w);

◆ Ethernet Uplink port supports 10/100/1000M adaptive;

◆ Flow control mode: full-duplex adopts IEEE 802.3x standard, half-duplex adopts Back pressure standard;

◆ Support IEEE802.3, IEEE802.3u, IEEE802.3x, IEEE802.3af/at;

◆ Support port auto flip (Auto MDI/MDIX);

◆ All ports support wire-speed switching;

◆ Automatically supplied to adaptive devices;

◆ Panel indicator monitoring status and help failure analysis;

◆ Natural cooling, compact size and quiet design, suitable for desktop or wall;

◆ Support VLAN Mode and Extend 250 meters Mode;

◆ Support 1U Rack Mount

Specifications

Technical parameter list
Product Name	8 ports 10/100Mbps POE Switch(8+2)
Product Model	HX802EP
DATA PIN	1/2+,3/6- 4/5+7/8-
Power Supply Type	Build In, 1/2+,3/6-
PoE Output Power	15.4W/30W
Connector	8100Mbps POE port, 2100mbps RJ45 Uplink
Network Medium	Cat5 (UTP) or more
Technology
Network Standards	IEEE 802.3i 10BASE-T IEEE 802.3u 100BASE-TXIEEE 802.3x Flow Control IEEE 802.3af Power over Ethernet
PoE power	15.4W per port(IEEE802.3af). Internal power supplyWiring: Data & power provided over pairs 1/2 and 3/6 or 4/5 (+) and 7/8(-)
Processing types	Store-and-forwardHalf-duplex back pressure and IEEE 802.3x full-duplex flow control
Address database Table Size	2K MAC address
Buffer memory	48Kb embedded memory per unit
Backboard Bandwidth	2Gbps Full duplex
Network Latency	Less than 20us for 64 byte frames in store-and-forward mode for 100Mbps to 100Mbps transmission
Power
Input	DC52V
PoE power consumption	15.4W per port(IEEE802.af/at)
Overload current protection	Present
Mechanical
Casing	Metal
Installation	DESKTOP/Rack mounting with Bracket
Interface
LED Indicators	System: Power, PoE Maximum powerPer port: Link, Activity, Speed, PoE active, PoE error
Environment specification
Operating temperature	-10-55℃(32-104℉)
Storage temperature	-40-70℃(14-158℉)
Operating humidity	90% maximum relative humidity, non-condensing
Storage humidity	95% maximum relative humidity, non-condensing
Regulatory Approval
ISO	Manufactured in ISO9001 facility
Safety	CE/CCC
Warranty	2 years
Dimensions	20011845mm (LWH)
Weight	N.W:0.98Kg , G.W:1.2Kg
