24V 1A POE Ethernet Switch Adapter

Product Detail

Model Number	HX-2401A
Input Voltage	100-240Vac, 50~60Hz (92~264Vac)
Input Current	0.6A(RMS) max.
Input Type	Wall mount type: POE15: EU, CN, US ect 2 pins plug
Output Voltage / Power	24Vdc 1A 24W
Output type	Single output 1RJ45 connector ---POE 1RJ45 connector ----LAN
Ethernet speed	10/100/Mbps Mega: Midspan (45/78) Or Endspan (12/36) 10/100/1000Mbps Gigabit :Midspan (45/78) Or Endspan (12/36)
Internet standard	IEEE802.3AF/802.3AT Compliance
Material	Plastic
Approval	CE/ROHS/FC
Warranty	2 years
Output Ripple	1% Max
Efficiency	≥83%
Response Time	<1ns
Combined Load Regualtion	±3%
Combined Line Regualtion	±5%
LED indicator	Power on, Green (With Plastic enclosure)
Operating Temp	0 to 40℃ (32 to 104℉)
Storage Temp	(-)20 to 85 ℃ ( -22 to 158 ℉)
Operating Humidity	10~ 90% Non condensing
Shipment	By Sea or By Air Express: DHL/UPS/TNT/FEDEX, ect
Package	Inner white box + Outer box
Carton Size:	460390200mm (LWH)
Qty/ Carton	50-100pcs
