24 Ports Ethernet Switch with 2 Gigabit SFP optical ports uplink network switch

Short Description:

HX-24G2SP is a 24 ports 10/100/1000Mbps POE + 2 Gigabit SFP optical ports Ethernet Power Switches. It is high-quality network IC and with very stable POE chips, POE switches provide seamless connection to 10 / 100 / 1000 M Ethernet, and the POE supply port can automatically detect and supply receiving devices meeting IEEE802.3af or IEEE802.3at standards, non-POE devices intelligently detect no power and only transmit data.

Send email to us

Product Detail

Applications

OUR FACTORY

Product Tags

Features

● 24 ports 10/100/1000Mbps POE + 2 Gigabit SFP optical ports;
● Support for the 1-8-port QOS priority;
● Support for port automatic flip (Auto MDI/MDIX);
● Support IEEE 802.3, IEEE 802.3u, IEEE 802.3u, IEEE802.3x standard;
● Compatible with IEEE802.3at (30W) and IEEE802.3af(15.4w)
● Ethernet Ports support 10/100/1000M self-adaptive;
● All ports support line-speed switching;
● The AI mode is automatically enabled 10M speed for Ports 7-8 in Extend mode;
● Flow control mode: full-duplex adopts IEEE 802.3x standard, half-duplex adopts Back pressure standard;
● Panel indicator monitoring status and help failure analysis;
● Zero configuration feature, automatically supplied to adaptive equipment;
● With DIP switch, support VLAN, Default and Extend modes;
● Support Surge protection: Common mode 4KV; ESD: Air 8KV, Contact 6KV.

Specifications

Product Model	HX-24G2SP
Product Name	24-Port Gigabit PoE switch
Total Power of Machine	300W/400W
Power	AC100-240V/50-60Hz
Ethernet	24* Gigabit PoE Ethernet Ports 2* Gigabit Uplink Ethernet Port
Switching Capacity	52Gbps
Pack forward rate	38.68Mpps
Giant frame	Giant frame
MAC Address	8K
Forward mode	Storage forwarding
Power Voltage	Input voltage: AC100-240V/50-60Hz Power supply power: 52V/5.76A
Working Environment	Working Temperature: -10~50°CStorage Temperature: -40~70°C Working Humidity: 10%~90%,non-condensing Storage Temperature: 5%~90%, non-condensing
